Industrial Energy Storage PCS 1.3–1.7MW | High‑Efficiency Bidirectional Power Conversion for Utility & C&I ESS
GreenMore's 1.3–1.7MW power storage converter (PCS) is a high-performance bidirectional power conversion system designed for utility-scale energy storage, renewable energy grid integration, microgrids, and industrial peak shaving applications. It supports parallel operation and can flexibly scale from 1MW to several MW configurations. The PCS utilizes industrial-grade components, intelligent control algorithms, and advanced grid support features to ensure stable, efficient, and safe power conversion in harsh grid environments.
Item No :
GM-LEG1575KPayment :
TT/LCProduct Origin :
ChinaCustom Made :
YesShipping Port :
Shanghai, Nanjing, Ningbo, Guangzhou, Shenzhen, etc.Lead Time :
20 daysWarranty :
3 yearsAdvanced three-level topology with silicon carbide devices, achieving up to 98% conversion efficiency for maximum system performance.
Compatible with DC 1500V battery systems and wide operating voltage range (800–1500V) for flexible system design.
Rugged cabinet design for harsh outdoor environments, ensuring long-term reliability from −30°C to +60°C.
Multi-level protection including insulation monitoring, surge protection, overheat protection, and anti-islanding functionality.
Multi-machine parallel operation enables scalable deployment from MW to multi-MW systems. Every unit is factory-tested for seamless integration.
Dynamic reactive power support and stable off-grid operation. Power factor adjustable from 0.99 leading to 0.99 lagging.
Built-in battery management enables flexible switching between peak-shaving, self-consumption, backup power, and grid support via MODBUS-RTU/TCP.
| Parameter | GM-LEG1250K | GM-LEG1575K | GM-LEG1725K |
|---|---|---|---|
| DC Input | |||
| Maximum DC Voltage (V) | 1500 | ||
| Minimum DC Voltage (V) | 800 | 915 | 1000 |
| DC Voltage Operating Range (V) | 800–1500 | 915–1500 | 1000–1500 |
| Maximum DC Current (A) | 1935 | ||
| AC Side (Grid-Connected) | |||
| Rated Output Power (kW) | 1250 | 1575 | 1725 |
| Maximum Output Power (kVA) | 1512 | 1732 | 1897 |
| Rated AC Current (A) | 1443 | ||
| Maximum AC Current (A) | 1587 | ||
| Rated AC Voltage (V) | 550 | 630 | 690 |
| AC Voltage Range (V) | 467.5–605 | 535.5–693 | 586.5–759 |
| Rated Grid Frequency (Hz) | 50 | ||
| Grid Frequency Range (Hz) | 45–55 | ||
| THD | <3% rated power | ||
| Power Factor | >0.99 rated power | ||
| Feed Phase / Output Phase | 3/3 | ||
| AC Side (Off-Grid) | |||
| Rated AC Voltage (V) | 550 | 630 | 690 |
| AC Voltage Range (V) | 467.5–605 | 535.5–693 | 586.5–759 |
| Rated Output Frequency (Hz) | 50 | ||
| AC Voltage Distortion Rate | <3% (Linear load) | ||
| DC Voltage Component (V) | <0.5% Un (Linear load) | ||
| Unbalanced Load Capacity | 100% | ||
| Protection | |||
| Surge Protection | Yes | ||
| Power Grid Monitoring | Yes | ||
| Overheat Protection | Yes | ||
| General Parameters | |||
| Maximum Efficiency | 98.0% | ||
| Isolation Transformer | No | ||
| Protection Level | IP54 | ||
| Cooling Method | Intelligent forced air cooling | ||
| Relative Humidity | 0–100% | ||
| Operating Temperature (°C) | −30 to +60 | ||
| Altitude (m) | 3000 | ||
| Dispatch Communication | RS485, CAN, Ethernet | ||
| Communication Protocol | MODBUS-RTU/TCP | ||
| Reference Weight (kg) | 1500 | ||
| Dimensions W×D×H (mm) | 1200 × 1450 × 2400 | ||
Updated on September 30, 2026
Q1: What is the function of the GreenMore PCS in an energy storage system?
The GreenMore PCS performs bidirectional AC-DC conversion, enabling batteries to charge and discharge efficiently. It stabilizes power flow, supports grid interaction, and provides reactive power compensation, black-start capability, and multi-mode operation.
Q2: Does the GreenMore PCS support 1500V DC battery systems?
Yes. The GM-LEG series supports DC 1500V input with a wide operating voltage range (800–1500V), compatible with modern large-scale battery systems for higher efficiency and lower system losses.
Q3: Can multiple GreenMore PCS units be connected in parallel?
Yes. The GreenMore PCS supports parallel operation, allowing multiple units to be combined for MW-level or multi-MW systems with flexible capacity expansion and improved reliability.
Q4: Is the GreenMore industrial PCS suitable for outdoor installation?
Yes. With IP54 protection and intelligent forced air cooling, it operates reliably from −30°C to +60°C, withstanding dust, rain, humidity, and extreme temperatures.
Q5: What safety features does the GreenMore PCS include?
Surge protection, power grid monitoring, overheat protection, insulation monitoring, and anti-islanding. Real-time fault detection and event logging ensure fast response. All units comply with CE/IEC/UL standards.
Q6: Does GreenMore offer OEM/ODM customization for this PCS?
Yes. Full OEM/ODM support including protocol adaptation, battery compatibility configuration, system integration, and branding. All products backed by a 3-year warranty and professional technical support since 2017.
CE/IEC/UL compliant design ensures market access globally. Meets grid-connection standards with real-time fault detection, event logging, and full operational transparency.
Surge protection, grid monitoring, overheat protection, insulation monitoring, anti-islanding, and E-STOP. Produced under strict industrial-grade specs with full burn-in testing before shipment.
Comprehensive warranty with dedicated technical support, spare parts availability, and remote monitoring capabilities throughout the product lifecycle.
Trusted Support: GreenMore has been delivering energy storage solutions since 2017, with dedicated technical support and remote monitoring for all industrial PCS products.
