5kW Off‑Grid Solar Power Station with LiFePO₄ Battery | All‑in‑One Backup Energy Storage System
The GreenMore 5kW Solar Power Station is a fully integrated off-grid energy storage system that combines a 5kW pure sine wave inverter, MPPT solar charge controller and 10.24kWh LiFePO₄ battery in a compact, stackable, plug-and-play unit. It supports solar charging, grid charging and generator input, making it suitable for homes, farms, cabins and remote sites where grid power is unreliable or unavailable.
Built with Grade-A LiFePO₄ cells and an intelligent BMS, the system provides multi-level protection against overcharge, over-discharge, short circuit and temperature extremes. Air cooling keeps noise below 60dB, with real-time monitoring through the GreenMore mobile app via RS485, CAN, WiFi and GPRS. Certified CE, IEC, MSDS and UN38.3, and backed by a 3-year warranty for customers across Europe, the Americas, the Middle East and Africa.
Item No :
GM-LEB5KPayment :
TT/LCProduct Origin :
ChinaCustom Made :
YesShipping Port :
Shanghai, Nanjing, Ningbo, Guangzhou, Shenzhen, etc.Lead Time :
20 daysWarranty :
3 years
All-in-One Integration
10.24kWh LFP
5kW Pure Sine Wave
Stackable Design
App Monitoring
The 5kW inverter, MPPT controller and LFP battery arrive in one unit, cutting wiring complexity and installation time while improving reliability on off-grid sites.
Four 51.2V LFP modules deliver long cycle life and strong thermal stability, with multi-layer BMS protection for consistent residential and remote-site performance.
Stack multiple units in parallel to expand from 10.24kWh to larger capacity as energy demands grow — no system replacement required.
Up to 5000VA continuous and 10000VA peak with THD under 3%; EPS transfer takes as little as 10ms, keeping sensitive loads running.
Real-time monitoring over CAN/RS485, WiFi and GPRS enables remote diagnostics and load management for installers and homeowners alike.
Air-cooled thermal management keeps the cabinet below 60dB across -10°C to +50°C, with OEM/ODM options for housing, branding and protocols.
Stable AC output for home appliances, with UPS-grade 10ms switching and support for solar, grid and battery input modes.
High-safety 51.2V LFP chemistry with up to 90% usable capacity, long cycle life and 200A charge/discharge capability.
80–450V MPPT voltage range supports up to 5000Wp PV arrays for maximum energy harvest in all-day sun conditions.
Multi-layer voltage, current and temperature protection with automatic cell balancing and real-time diagnostics via RS485/CAN/WiFi/GPRS.
Quiet operation below 60dB and low maintenance, with stable performance across -10°C to +50°C operating conditions.
| Model | GM-LEB5K |
| PV Input | |
| Maximum PV Array Power (Wp) | 5000 |
| Maximum Input Voltage (V) | 500 |
| Start-up Voltage (V) | 100 |
| MPPT Voltage Range (V) | 80–450 |
| Full-Load MPPT Voltage (V) | 280–400 |
| MPPT Channels / Strings per Channel | 1 / 1 |
| Maximum Input Current (A) | 22 |
| AC Input (Mains) | |
| Rated Input Voltage (V) | 230 |
| Selectable Voltage Range (V) | 170–280 (UPS) / 120–280 (appliances) |
| Undervoltage / Recovery (V) | 170±7 / 180±7 (UPS); 120±7 / 130±7 (appliances) |
| Overvoltage / Recovery (V) | 280±7 / 270±7 |
| Maximum Input Voltage (V) | 300 |
| Rated Input Frequency (Hz) | 50/60 adaptive |
| Efficiency | |
| AC Power Mode | >95% (purely resistive load, battery full) |
| Maximum Efficiency | 93% |
| Max Bypass Overload Current (A) | 40 |
| Emergency Power Output (EPS) | |
| Rated Output Power (VA) | 5000 |
| Maximum Output Power (VA) | 10000 |
| Maximum Output Current (A) | 22 |
| Rated Output Voltage (V) | 230 ±5% |
| Output Frequency (Hz) | 50 |
| THDu (Linear Load) | <3% |
| Switching Time | 10ms (UPS) / 20ms (appliances) |
| Battery | |
| Battery Cells | LiFePO₄ 3.2V / 100Ah |
| Rated Capacity (kWh) | 10.24 |
| Number of Modules | 4 |
| Rated Voltage (V) | 51.2 |
| Operating Voltage Range (V) | 44.8–58.2 |
| Max Charge / Discharge Current (A) | 200 / 200 |
| Maximum Depth of Discharge (DoD) | 90% |
| Cycle Life | 6,000+ cycles @80% DOD |
| General Parameters | |
| Protection Level | IP54 |
| Cooling Method | Air cooling |
| Relative Humidity | 5–95%, non-condensing |
| Operating Temperature (°C) | -10 to +50 |
| Noise (dB) | <60 |
| Display | LCD |
| Communication | RS485 / CAN / WiFi / GPRS |
| Weight | 113.6kg |
| Dimensions (W×D×H) | 550×380×697mm |
| Certification | CE, IEC, MSDS, UN38.3 |
| Warranty | 3 years |
Note: Product dimensions and parameters are subject to the actual delivered product. Updated on October 1, 2026.
Store excess solar energy during the day and use it at night. A single 5kW station with 10.24kWh storage covers evening loads — lighting, refrigeration, TV and AC — reducing grid dependence and electricity bills.
Remote farms and barns with unreliable power can run irrigation pumps, ventilation, lighting and feeding equipment. Stack additional units as the operation expands.
In areas with frequent blackouts or voltage fluctuations, the built-in EPS switches to battery power within 10ms. Critical loads — refrigerators, medical equipment, communication devices — stay online seamlessly.
Integrated energy storage units serve as emergency backup in areas with unstable power. The seamless EPS switching ensures continuous operation of critical loads until grid power returns.
Telecom towers, monitoring stations and off-grid shops need dependable power year-round. With IP54 protection and -10°C to +50°C operation, this system is a quiet, low-maintenance alternative to diesel generators.
CE, IEC, MSDS and UN38.3 certification covers international safety and battery transport; every unit is full-capacity tested before shipment.
Voltage, current and temperature monitoring with overcharge, over-discharge, short-circuit and imbalance protection, plus automatic cell balancing.
Since 2017 GreenMore has focused on safe, reliable off-grid storage built with Grade-A LFP cells, under control from incoming material to final test.
Trusted Support
Wiring diagrams, installation manuals and remote technical guidance, app-based diagnostics, and a 3-year warranty with dedicated engineering support for distributors and installers. Explore our full home energy storage range.
It supports essential household and light commercial loads — lighting, refrigerators, fans, water pumps, TVs and electronics. With 10.24kWh storage, it typically provides 4–10 hours of backup depending on load size.
Grade-A LFP cells are rated for 6,000+ cycles at 80% DOD, supporting 15+ years of daily use under normal conditions. The system is covered by a 3-year warranty.
Yes. The modular design supports parallel expansion, allowing you to start small and scale capacity as energy needs grow — without replacing the existing system.
Yes. LiFePO₄ chemistry is thermally stable and non-toxic. The smart BMS provides multi-level protection against overcharge, over-discharge, short circuit and temperature extremes.
The MPPT controller supports up to 5000Wp PV arrays with an 80–450V voltage range. The system also accepts grid charging and generator input as backup power sources.
The built-in EPS function switches to battery power in as little as 10ms (UPS mode), keeping computers, routers and medical devices running without interruption.
