Stackable Home & Commercial ESS | 6KW Hybrid Inverter + 20.48KWh Lithium Storage
The GreenMore GM-LEB6K is a stackable home and commercial energy storage system that integrates a 6KW pure sine wave hybrid inverter with a 51.2V 20.48kWh LiFePO₄ battery. It supports grid-tied, off-grid and hybrid operation with an 80–450V MPPT range, compatible with a wide range of solar panel configurations. The modular design allows up to 32 units in parallel, scaling from 20.48kWh to 655.4kWh for residential, commercial and light industrial installations.
Built with Grade-A LiFePO₄ cells and a smart BMS, the system protects against overcharge, over-discharge, short circuit and temperature extremes. Natural air cooling keeps noise below 60dB for quiet indoor operation. Battery status, power flow and alerts are tracked in real time through the GreenMore mobile app. Backed by a 3-year warranty and trusted by customers across Europe, the Americas, the Middle East and Africa.
Item No :
GM-LEB6KPayment :
TT/LCProduct Origin :
ChinaCustom Made :
YesLead Time :
20 daysWarranty :
3 yearsThe GreenMore GM-LEB6K is a stackable home and commercial energy storage system that integrates a 6KW pure sine wave hybrid inverter with a 51.2V 20.48kWh LiFePO₄ battery. It supports grid-tied, off-grid and hybrid operation with an 80–450V MPPT range, compatible with a wide range of solar panel configurations. The modular design allows up to 32 units in parallel, scaling from 20.48kWh to 655.4kWh for residential, commercial and light industrial installations.
Built with Grade-A LiFePO₄ cells and a smart BMS, the system protects against overcharge, over-discharge, short circuit and temperature extremes. Natural air cooling keeps noise below 60dB for quiet indoor operation. Battery status, power flow and alerts are tracked in real time through the GreenMore mobile app. Backed by a 3-year warranty and trusted by customers across Europe, the Americas, the Middle East and Africa.
Smart BMS
App Monitoring
Safety Protection
Scalable Design
3.2V/100Ah square cells deliver 6000+ cycles at 80% DOD with strong thermal stability and no thermal runaway under normal operating conditions.
6000VA rated output with 12000VA peak, pure sine wave at 230V single phase; grid-tied, off-grid and hybrid modes in one unit.
EPS function transfers sensitive loads in as fast as 10ms — computers, routers and medical devices keep running through blackouts.
6000Wp max array, 1 MPPT channel, start-up at 100V — covers most mono and polycrystalline panel configurations.
Track SOC, power flow, cycles and alerts from anywhere; RS485/CAN plus WiFi and GPRS options keep the system connected.
Air cooling holds noise below 60dB with no liquid loop — suitable for indoor residential spaces and low on upkeep.
| Product Model | GM-LEB6K |
|---|---|
| PV Input | |
| Max PV Array Power | 6000Wp |
| Max Input Voltage | 500V |
| Start-up Voltage | 100V |
| MPPT Voltage Range | 80–450V |
| Full-Load MPPT Voltage | 280–400V |
| MPPT Channels / Strings | 1 / 1 |
| Max Input Current | 22A |
| AC Input (Mains) | |
| Rated Input Voltage | 230V |
| Selectable Range | 170–280V (UPS); 120–280V (Appliances) |
| Rated Frequency | 50/60Hz adaptive |
| AC Output | |
| Rated Output Power | 6000VA |
| Max Output Power | 12000VA |
| Rated Output Voltage | 230V ±5% |
| Output Frequency | 50/60Hz |
| THD | <3% (linear load) |
| Switching Time | 10ms (UPS) / 20ms (Appliances) |
| Battery | |
| Battery Type | LiFePO₄, 3.2V/100Ah square cells |
| Rated Capacity | 20.48kWh |
| Rated Voltage | 51.2V |
| Operating Voltage | 44.8–58.2V |
| Max Charge / Discharge Current | 400A / 400A |
| Max DoD | 90% |
| Cycle Life | 6000+ cycles at 80% DOD |
| Parallel Expansion | Up to 32 units (max 655.4kWh) |
| General | |
| Protection Level | IP54 |
| Cooling Method | Air cooling |
| Noise | <60dB |
| Display | LCD |
| Communication | RS485 / CAN / WiFi / GPRS |
| Dimensions (W×D×H) | 560×160×1796 mm |
| Weight | 166 kg |
| Operating Temperature | -10°C to +50°C |
| Warranty | 3 years |
Note: Product dimensions and parameters are subject to the actual delivered product. Updated on October 1, 2026.
One 20.48kWh unit carries an average household through the evening — air conditioning, fridge, lighting and entertainment — cutting grid draw and electricity bills.
Stack units for shops, offices, workshops and small factories facing frequent outages; 6KW output supports refrigeration, POS, lighting and light machinery.
Cabins, farms, telecom towers and monitoring stations run 24/7 on a 6000Wp solar array — zero fuel costs and minimal upkeep.
Charge at off-peak rates and discharge at peak periods; app-based scheduling follows time-of-use tariffs and reduces demand charges.
CE, IEC, MSDS and UN38.3 certification covers international safety and battery transport standards; every unit is fully capacity-tested before shipment.
Overcharge, over-discharge, over-current, short circuit, over-temperature and cell imbalance protection, with all data visible in the mobile app.
Since 2017 GreenMore has built storage systems around Grade-A cells from qualified suppliers, under quality control from incoming material to final test.
Trusted Support
Remote technical guidance for installation and commissioning, app-based monitoring, and a 3-year warranty with repair or replacement service. Compare this system with our full home energy storage range.
Up to 32 units, reaching 655.4kWh — the system scales from a single-phase home to a small factory or commercial facility.
Yes — EPS switches in as fast as 10ms in UPS mode, keeping computers, routers and medical devices running without interruption.
80–450V MPPT with a 6000Wp array and 1 channel covers most mono and polycrystalline setups; we can recommend configurations for your site.
6000+ cycles at 80% DOD supports 15+ years of daily use. The 3-year warranty covers manufacturing defects and BMS failures.
Thermally stable, non-toxic LFP chemistry, noise below 60dB and an IP54 rating make indoor installation straightforward.
Remote installation and commissioning guidance, mobile app monitoring and a 3-year repair-or-replacement warranty, supported across four continents.
